See More Wiring Diagrams for Installing a Ceiling Fan
My choice is to connect the Red and Black wires together at the wall switch therefore if separate switches would ever be installed then the changes with the wiring may be done at the wall switch and not require disassembling the ceiling fan to change the wiring up at the ceiling fan box.Įxample: Wiring a Switch for a Ceiling Fan Light. Connect the Black and Red wire together at the ceiling fan box. Connect the Black and Red wires together at the switch box. If there will be only one switch that will be used at the wall then as this question states, there are two options:. Optional Wiring Configurations for One Switch. Please refer to the Ceiling Fan Wiring Diagrams for additional clarification. NOTE: The circuit power source is a separate cable which has a black wire (power), white wire (neutral), and the ground wire which is either bare copper or a green wire. The White neutral wires are spliced together. Optional: The light switch could be a dimmer switch if the dimmer switch and the type of light bulbs are compatible and have dimming capabilities. The Red wire is for a separate switch for the light of the ceiling fan. The red wire from the wall switch typically connects to the Blue wire of the ceiling fan, which is for the light fixture. Optional: This switch could be a variable speed control switch. This black wire typically connects to the black wire of the ceiling fan. The Black wire is for a separate switch for the ceiling fan motor. This 3-wire cable will provide the following switch functions: Ceiling fan control switch install#
When installing the wiring for a ceiling fan from a wall switch box where the circuit power originates, it is common to install a 3-wire cable from the wall switch box up to the ceiling fan. When the Power for the Ceiling Fan Starts at the Wall Switch. Wiring Connections for a Ceiling Fan and Switches Precaution: Identify the ceiling fan circuit, turn it OFF and Tag it with a Note before working with the electrical wiring. Tools Required: Basic Electricians Pouch Hand Tools, a fiberglass or non-aluminum ladder and Voltage Tester.Įstimated Time: Depends on personal level experience, ability to work with tools and access to the ceiling fan location. This electrical wiring project is best performed by a Licensed Electrical Contractor or Certified Electrician. Ceiling fan control switch how to#
Wiring Ceiling Fans and Wall SwitchesĪpplication: How to Wire a Ceiling Fan and the Wall Switches. Thanks for your electrical wiring question Steve. This electrical wiring question came from: Steve, from Sunlakes, Arizona.Īdditional Comments: Just discovered the site and have signed up for your Electrical How-To Manual. I probably should remove the red wire that is currently attached to the wall switch.With a new fan I don’t think the red wire is required so I should be able to extend the existing 4-wire cable up to the new fan location using a 3-wire cable instead.
All the wires had to be connected together.
Note that the “old” fan is about 15 years old and there are no factory installed wire connectors for the light. Why just not wire nut them at the ceiling box rather than run two hot wires off the same wall switch? I don’t understand the logic behind this. It looks like the red wire was being used to power the lights and the black for the fan. When the switch was turned on power was sent to both the red and black wires going to the fan. It was inserted into the push-in terminal while the black wire was attached to the screw terminal. What I found was the “hot” or feed wire attached to the bottom terminal of the wall switch (normal so far), the “hot” black wire to the fan was attached to the top terminal (again normal), but then I found a red wire also attached to the same top lug of the switch. The main circuit cable to the switch is a 3-wire, black, white, ground. I then inspected the fan wall switch which is a standard on and off switch, no other switches, and dimmers. I have installed quite a few ceiling fans the past couple of years and all of them even with light kits were set up for three wire boxes. When I removed the old fan I found four wires coming out of the box. I am relocating an existing ceiling fan from a lower portion of a vaulted ceiling to a higher point on the ceiling. I am wiring a ceiling fan and it looks like the red wire at the switch was being used to power the lights and the black for the fan, so why not connect the wires together at the ceiling box rather than run two hot wires off the same wall switch? Electrical Question: Can I connect the wires together at the ceiling box rather than run two hot wires off the wall switch?
